Organized assemblies of single wall carbon nanotubes and porphyrin for photochemical solar cells: charge injection from excited porphyrin into single-walled carbon nanotubes

Photochemical solar cells have been constructed from organized assemblies of single-walled carbon nanotubes (SWCNT) and protonated porphyrin on nanostructured SnO2 electrodes. The protonated form of porphyrin (H4P2+) and SWCNT composites form 0.5-3.0 microm-sized rodlike structures and they can be assembled onto nanostructured SnO2 films [optically transparent electrode OTE/SnO2] by an electrophoretic deposition method. These organized assemblies are photoactive and absorb strongly in the entire visible region. The incident photon to photocurrent efficiency (IPCE) of OTE/SnO2/SWCNT-H4P2+ is approximately 13% at an applied potential of 0.2 V versus saturated calomel electrode. Femtosecond pump-probe spectroscopy experiments confirm the decay of the excited porphyrin in the SWCNT-H4P2+ assembly as it injects electrons into SWCNT. The dual role of SWCNT in promoting photoinduced charge separation and facilitating charge transport is presented.

Host-guest interactions in the supramolecular incorporation of fullerenes into tailored holes on porphyrin-modified gold nanoparticles in molecular photovoltaics

Novel gold nanoparticles modified with a mixed self-assembled monolayer of porphyrin alkanethiol and short-chain alkanethiol were prepared (first step) to examine the size and shape effects of surface holes (host) on porphyrin-modified gold nanoparticles. The porphyrin-modified gold nanoparticles with a size of about 10 nm incorporated C60 molecules (guest) into the large, bucket-shaped holes, leading to the formation of a supramolecular complex of porphyrin-C60 composites (second step). Large composite clusters with a size of 200-400 nm were grown from the supramolecular complex of porphyrin-C60 composites in mixed solvents (third step) and deposited electrophoretically onto nanostructured SnO2 electrodes (fourth step). Differences in the porphyrin:C60 ratio were found to affect the structures and photoelectrochemical properties of the composite clusters in mixed solvents as well as on the SnO2 electrodes. The photoelectrochemical performance of a photoelectrochemical device consisting of SnO2 electrodes modified with the porphyrin-C60 composites was enhanced relative to a reference system with small, wedged-shaped surface holes on the gold nanoparticle. Time-resolved transient absorption spectroscopy with fluorescence lifetime measurements suggest the occurrence of ultrafast electron transfer from the porphyrin excited singlet states to C60 or the formation of a partial charge-transfer state in the composite clusters of supramolecular complexes formed between porphyrin and C60 leading to efficient photocurrent generation in the system. Elucidation of the relationship between host-guest interactions and photoelectrochemical function in the present system will provide valuable information on the design of molecular devices and machines including molecular photovoltaics.

Quaternary self-organization of porphyrin and fullerene units by clusterization with gold nanoparticles on SnO2 electrodes for organic solar cells

Novel organic solar cells prepared using quaternary self-organization of porphyrin (donor) and fullerene (acceptor) dye units by clusterization with gold nanoparticles on SnO2 electrodes exhibit the remarkable enhancement of the photoelectrochemical properties relative to the reference systems.

A photoelectrochemical device with a nanostructured SnO2 electrode modified with composite clusters of porphyrin-modified silica nanoparticle and fullerene

A silica nanoparticle has been successfully employed as a nanoscaffold to self-organize porphyrin and C60 molecules on a nanostructured SnO2 electrode. The quenching of the porphyrin excited singlet state on the silica nanoparticle is suppressed significantly, showing that silica nanoparticles are promising scaffolds for organizing photoactive molecules three-dimensionally in nanometer scale. Marked enhancement of the photocurrent generation was achieved in the present system compared with the reference system, where a gold core was employed as a scaffold of porphyrins instead of a silica nanoparticle. The rather small incident photon-to-current efficiency relative to a similar photoelectrochemical device using a silica microparticle may result from poor electron and hole mobility in the composite film due to poor connection between the composite clusters of a porphyrin-modified silica nanoparticle and C60 in micrometer scale.

Nanostructured thin films of C60-aniline dyad clusters: electrodeposition, charge separation, and photoelectrochemistry

Clusters of C60-aniline dyads are deposited as thin films on nanostructured SnO2 electrodes under the influence of an electric field. At low applied DC voltage (<5 V) the clusters in toluene/acetonitrile (1:3) mixed solvent grow in size (from 160 nm to approximately 200 nm in diameter) while at higher voltages (>50 V) they are deposited on the electrode surface as thin films. The C60- aniline dyad cluster films when cast on nanostructured SnO2 films are photoelectrochemically active and generate photocurrent under visible light excitation. These nanostructured fullerene films are capable of delivering relatively large photocurrents (up to approximately 0.2 mA cm(-2), photoconversion efficiency of 3-4%) when employed as photoanodes in photoelectrochemical cells. Both luminescence and transient absorption studies confirm the formation of charge transfer product (C60 anion) following UV/Vis excitation of these films. Photo-induced charge separation in these dyad clusters is followed by the electron injection from C60-anion moiety into the SnO2 nanocrystallites. The oxidized counterpart is reduced by the redox couple present in the electrolyte, thus regenerating the dyad clusters. The feasibility of casting high surface area thin fullerene films on electrode surfaces has opened up new avenues to utilize dyad molecules of sensitizer bridge donor type in light energy conversion devices, such as solar cells.

Hydrogen bonding effects on the surface structure and photoelectrochemical properties of nanostructured SnO2 electrodes modified with porphyrin and fullerene composites

Hydrogen bonding effects on surface structure, photophysical properties, and photoelectrochemistry have been examined in a mixed film of porphyrin and fullerene composites with and without hydrogen bonding on indium tin oxide and nanostructured SnO2 electrodes. The nanostructured SnO2 electrodes modified with the mixed films of porphyrin and fullerene composites with hydrogen bonding exhibited efficient photocurrent generation compared to the reference systems without hydrogen bonding. Atomic force microscopy, infrared reflection absorption, and ultraviolet-visible absorption spectroscopies and time-resolved fluorescence lifetime and transient absorption spectroscopic measurements disclosed the relationship between the surface structure and photophysical and photoelectrochemical properties relating to the formation of hydrogen bonding between the porphyrins and/or the C60 moieties in the films on the electrode surface. These results show that hydrogen bonding is a highly promising methodology for the fabrication of donor and acceptor composites on nanostructured semiconducting electrodes, which exhibit high photoelectrochemical properties.

Effects of porphyrin substituents on film structure and photoelectrochemical properties of porphyrin/fullerene composite clusters electrophoretically deposited on nanostructured SnO2 electrodes

We have systematically examined the substituent effects of meso-tetraphenylporphyrins on film structures and the photoelectrochemical properties of the composite clusters of free-base porphyrin and C(60) electrophoretically deposited on nanostructured SnO(2) electrodes. The photocurrent generation efficiency was found to correlate with the complexation ability of the porphyrin for C(60). Basically, the incident photon-to-current efficiency (IPCE) value was increased with increasing relative amounts of the porphyrin versus C(60) in the films. The unique molecular arrangement of the porphyrin with the simple, specific substituents (i.e., methoxy groups at the meta-positions of the meso-phenyl rings of tetraphenylporphyrins (3,5-OMeTPP; TPP=tetraphenylporphyrin)) and C(60) on SnO(2) electrodes resulted in the largest IPCE value (ca. 60 %) among this type of photoelectrochemical device. The rapid formation of the composite clusters and microcrystals from the combination of 3,5-OMeTPP and C(60) in a mixed solvent is unique as the association is accelerated by intermolecular interactions (i.e., hydrogen-bonding and CH-pi interactions) between the methoxy groups of the porphyrins and the porphyrin/C(60), in addition to the pi-pi interactions between the porphyrins/C(60) and C(60) molecules. Both the films and single crystals composed of the porphyrin and C(60) exhibited remarkably high electron mobility (7x10(-2) and 0.4 cm(2) V(-1) s(-1)), which is comparable to the value for highly efficient bulk heterojunction solar cells. Our experimental results have successfully demonstrated the importance of nanostructured electron- and hole-transporting pathways in bulk heterojunction solar cells. Such a finding will provide basic and valuable information on the design of molecular photovoltaics at the molecular level.

Effects of fullerene substituents on structure and photoelectrochemical properties of fullerene nanoclusters electrophoretically deposited on nanostructured SnO2 electrodes

Two kinds of fullerene derivatives have been designed to examine the effect of the fullerene substituents on the structure and photoelectrochemical properties of fullerene clusters electrophoretically deposited on nanostructured SnO(2) electrodes. The cluster sizes increase and the incident photon-to-current efficiencies decrease with introduction of large substituents into C(60). The trend for photocurrent generation efficiency as well as surface morphology on the electrode can be explained by the steric bulkiness around the C(60) molecules. A C(60) molecule with two alkoxy chains is suggested to give a bilayer vesicle structure, irrespective of the hydrophobic nature of both the C(60) and alkoxy chain moieties. Such information will be valuable for the design of photoactive molecules, which are fabricated onto electrode surfaces to exhibit high energy conversion efficiency.

Quantum dot solar cells. Electrophoretic deposition of CdSe-C60 composite films and capture of photogenerated electrons with nC60 cluster shell

Encapsulation with a nC60 cluster shell facilitates capture of photogenerated electrons from CdSe quantum dots following visible light excitation. Electrophoretic deposition of CdSe-C60 composite clusters on optically transparent electrodes (OTE/SnO2) produce photoactive films that exhibit photoelectrochemical activity. The observed photoconversion efficiency (IPCE) of approximately 4% is significantly greater than those observed with CdSe or nC60 films.

Structure and photoelectrochemical properties of nanostructured SnO2 electrodes deposited electrophoretically with the composite clusters of porphyrin-modified gold nanoparticle with a long spacer and fullerene

Structure and photoelectrochemical properties of nanostructured SnO₂ electrodes deposited electrophoretically with the composite clusters of porphyrin-modified gold nanoparticle with a long, flexible spacer and C₆₀ molecules have been examined to obtain basic information on the development of organic solar cells with a high performance. The photoelectrochemical system with the long, flexible spacer between the porphyrin and the gold nanoparticle in the porphyrin-modified gold nanoparticle exhibited comparable external quantum yield in the UV-vis regions relative to porphyrin-modified gold nanoparticle with a relatively short spacer—C₆₀ composite reference system. These results demonstrate that a suitable spacer to incorporate C₆₀ molecules efficiently between the porphyrins in porphyrin-modified gold nanoparticles is a prerequisite for improving the performance of porphyrin and fullerene-based organic solar cells.

Efficient photocurrent generation by SnO2 electrode modified electrophoretically with composite clusters of porphyrin-modified silica microparticle and fullerene

A silica microparticle has been successfully employed as a nanoscaffold to self-organize porphyrin and C60 molecules on a nanostructured SnO2 electrode which exhibits efficient photocurrent generation.

Clusterization, electrophoretic deposition, and photoelectrochemical properties of fullerene-functionalized carbon nanotube composites

We have successfully developed a new methodology for the self-organization of C(60) molecules on the sidewall of carbon nanotubes for use in photoelectrochemical devices. Novel nanocarbon composites of fullerene (e.g., C(60)) and highly soluble, chemically functionalized single-walled carbon nanotubes (f-SWNT) have been prepared by the rapid injection of a poor solvent (e.g., acetonitrile) into a mixed solution of C(60) and f-SWNT in o-dichlorobenzene. Measurements by using scanning electron microscopy of cast samples revealed that the composites are categorized into three groups; i) f-SWNT bundles covered with layers of C(60) molecules, ii) round, large C(60) clusters (sizes of 500-1000 nm) containing f-SWNT, and iii) typical, round C(60) clusters (sizes of 150-250 nm). The electrophoretic deposition of the composites onto a nanostructured SnO(2) electrode yielded the hierarchical film with a gradient composition depending on the difference in the mobilities of C(60) and f-SWNT during the electrophoretic process. The composite film exhibited an incident photon-to-photocurrent efficiency as high as 18 % at lambda=400 nm under an applied potential of 0.05 V vs. SCE. The photocurrent generation efficiency is the highest value among carbon nanotube-based photoelectrochemical devices in which carbon nanotubes are deposited electrophoretically, electrostatically or covalently onto semiconducting electrodes. The highly aligned structure of C(60) molecules on f-SWNT can rationalize the efficient photocurrent generation. The results obtained here will provide valuable information on the design of carbon nanotube-based molecular devices.

Supramolecular nanostructured assemblies of different types of porphyrins with fullerene using TiO2 nanoparticles for light energy conversion

TiO₂ nanoparticles were modified with porphyrin derivatives, 5-[4-benzoic acid]-10,15,20-tris[3,5-di-tert-butylphenyl]-21H,23H-porphyrin (Ar-H₂P-COOH), 5-[4-benzoic acid]-10,20-tris[3,5-di-tert-butylphenyl]-21H,23H-porphyrin (H-H₂P-COOH), and 5,10,15,20-tetra[4-benzoic acid]-21H,23H-porphyrin (H₂P-4COOH). The porphyrin-modified TiO₂ nanoparticles were deposited on nanostructured OTE/SnO₂ electrode together with nanoclusters of fullerene (C₆₀) in acetonitrile-toluene (3/1, v/v) using an electrophoretic deposition technique to afford the porphyrin-modified TiO₂ composite electrode denoted as OTE/SnO₂/(porphyrin-modified TiO₂ nanoparticle+C₆₀)_n. The porphyrin-modified TiO₂ composite electrodes have efficient light absorbing properties in the visible region, exhibiting the photoactive response under visible light excitation using redox couple. The incident photon-to-photocurrent efficiency (IPCE) values of supramolecular nanostructured electrodes of porphyrin-modified TiO₂ nanoparticles with fullerene [OTE/SnO₂/(Ar-H₂P-COO-TiO₂+C₆₀)_n, OTE/SnO₂/(H-H₂P-COO-TiO₂+C₆₀)_n, and OTE/SnO₂/(H₂P-4COO-TiO₂+C₆₀)_n] are much larger than those of the reference systems of porphyrin-modified TiO₂ nanoparticles without C₆₀ [OTE/SnO₂/(Ar-H₂P-COO-TiO₂)_n, OTE/SnO₂/(H-H₂P-COO-TiO₂)_n, and OTE/SnO₂/(H₂P-4COO-TiO₂)_n]. In particular, the maximum IPCE value (41%) is obtained for OTE/SnO₂/(H-H₂P-COO-TiO₂+C₆₀)_n under the bias potential of 0.2 V versus SCE. This indicates that the formation of supramolecular complexes between porphyrins and fullerene on TiO₂ nanoparticles plays an important role in improvement of the light energy conversion properties.

Control over photoinduced energy and electron transfer in supramolecular polyads of covalently linked azaBODIPY-bisporphyrin 'molecular clip' hosting fullerene

A 'molecular clip' featuring a near-IR emitting fluorophore, BF(2)-chelated tetraarylazadipyrromethane (aza-BODIPY) covalently linked to two porphyrins (MP, M = 2H or Zn) has been newly synthesized to host a three-dimensional electron acceptor fullerene via a 'two-point' metal-ligand axial coordination. Efficient singlet-singlet excitation transfer from (1)ZnP* to aza-BODIPY was witnessed in the dyad and triad in nonpolar and less polar solvents, such as toluene and o-dichlorobenzene, however, in polar solvents, additional electron transfer occurred along with energy transfer. A supramolecular tetrad was formed by assembling bis-pyridine functionalized fullerene via a 'two-point' metal-ligand axial coordination, and the resulted complex was characterized by optical absorption and emission, computational, and electrochemical methods. Electron transfer from photoexcited zinc porphyrin to C(60) is witnessed in the supramolecular tetrad from the femtosecond transient absorption spectral studies. Further, the supramolecular polyads (triad or tetrad) were utilized to build photoelectrochemical cells to check their ability to convert light into electricity by fabricating FTO/SnO(2)/polyad electrodes. The presence of azaBODIPY and fullerene entities of the tetrad improved the overall light energy conversion efficiency. An incident photon-to-current conversion efficiency of up to 17% has been achieved for the tetrad modified electrode.

Platinum Electrocatalysts Deposited onto Composite Carbon Black–Metal Oxide Support

Russian Journal of Electrochemistry - New nanostructured Pt/(SnO2/C)-electrocatalyst (20 wt % Pt) is synthesized via platinum chemical deposited onto composite SnO2/C-support microparticles (4 wt %...

Gold nanoparticle enhanced charge transfer in thin film assemblies of porphyrin-fullerene dyads

Photoinduced vectorial electron transfer in a molecularly organized porphyrin-fullerene (PF) dyad film is enhanced by the interlayer charge transfer from the porphyrin moiety of the dyad to an octanethiol protected (dcore approximately 2 nm) gold nanoparticle (AuNP) film. By using the time-resolved Maxwell displacement charge (TRMDC) method, the charge separation distance was found to increase by 5 times in a multilayer film structure where the gold nanoparticles face the porphyrin moiety of the dyad, that is, AuNP|PF, compared to the case of the PF layer alone. Films were assembled by the Langmuir-Blodgett (LB) method using octadecylamine (ODA) as the matrix compound. Atomic force microscopy (AFM) images of the monolayers revealed that AuNPs are arranged into continuous, islandlike structures and PF dyads form clusters. The porphyrin reference layer was assembled with the AuNP layer to gain insight on the interaction mechanism between porphyrin and gold nanoparticles. Interlayer electron transfer was also observed between the AuNPs and porphyrin reference, but the efficiency is lower than that in the AuNP|PF film. Fluorescence emission of the reference porphyrin is slightly quenched, and fluorescence decay becomes faster in the presence of AuNPs. The proposed mechanism for the electron transfer in the AuNP|PF film is thus the primary electron transfer from the porphyrin to the fullerene followed by a secondary hole transfer from the porphyrin to the AuNPs, resulting in an increased charge separation distance and enhanced photovoltage.

SnO2-TiO2薄膜载体对Au-Pt纳米颗粒电化学性能的影响

采用真空镀膜法在玻碳(GC)电极表面修饰SnO2-TiO2薄膜, 在SnO2-TiO2/GC复合电极表面组装Au-Pt双金属纳米颗粒, 制得Au-Pt/SnO2-TiO2/GC复合电极. 通过循环伏安法(CV)研究了SnO2-TiO2薄膜载体对Au-Pt双金属纳米颗粒电化学性能的影响; 采用扫描电镜(SEM)及X射线光电子能谱(XPS)对Au-Pt在SnO2-TiO2薄膜沉积的形貌及结构进行了表征. 研究结果表明, 10 nm的Au-Pt双金属纳米颗粒均匀地组装于SnO2-TiO2薄膜表面; SnO2-TiO2薄膜载体改善了复合电极抗CO中毒能力; Au-Pt双金属合金的形成提高了Pt 对甲醇氧化的电催化能力, SnO2-TiO2薄膜载体又使Pt纳米粒子d空轨道增多, 提高了Au-Pt双金属纳米颗粒的稳定性和催化性能.

Photovoltaic properties of self-assembled monolayers of porphyrins and porphyrin-fullerene dyads on ITO and gold surfaces

A systematic series of ITO electrodes modified chemically with self-assembled monolayers (SAMs) of porphyrins and porphyrin-fullerene dyads have been designed to provide valuable insight into the development of artificial photosynthetic devices. First the ITO and gold electrodes modified chemically with SAMs of porphyrins with a spacer of the same number of atoms were prepared to compare the effects of energy transfer (EN) quenching of the porphyrin excited singlet states by the two electrodes. Less EN quenching was observed on the ITO electrode as compared to the EN quenching on the corresponding gold electrode, leading to remarkable enhancement of the photocurrent generation (ca. 280 times) in the porphyrin SAMs on the ITO electrode in the presence of the triethanolamine (TEA) used as a sacrificial electron donor. The porphyrin (H(2)P) was then linked with C(60) which can act as an electron acceptor to construct H(2)P-C(60) SAMs on the ITO surface in the presence of hexyl viologen (HV(2+)) used as an electron carrier in a three electrode system, denoted as ITO/H(2)P-C(60)/HV(2+)/Pt. The quantum yield of the photocurrent generation of the ITO/H(2)P-C(60)/HV(2+)/Pt system (6.4%) is 30 times larger than that of the corresponding system without C(60): ITO/H(2)P-ref/HV(2+)/Pt (0.21%). Such enhancement of photocurrent generation in the porphyrin-fullerene dyad system is ascribed to an efficient photoinduced ET from the porphyrin singlet excited state to the C(60) moiety as indicated by the fluorescence lifetime measurements and also by time-resolved transient absorption studies on the ITO systems. The surface structures of H(2)P and H(2)P-C(60) SAMs on ITO (H(2)P/ITO and H(2)P-C(60)/ITO) have been observed successfully in molecular resolution with atomic force microscopy for the first time.

Structure and photoelectrochemical properties of phthalocyanine and perylene diimide composite clusters deposited electrophoretically on nanostructured SnO2 electrodes

Clusters of phthalocyanine and phthalocyanine-perylene diimide have been prepared and electrophoretically deposited on nanostructured SnO2 electrodes. The structure and photoelectrochemical properties of the clusters have been investigated by using UV-visible absorption, dynamic light scattering (DLS), atomic force microscopy (AFM), transmission electron microscopy (TEM), and photoelectrochemical and photodynamical measurements. Enhancement of the photocurrent generation efficiency in the composite system has been achieved relative to that in the phthalocyanine reference system without the perylene diimide. Such information will be valuable for the design of molecular photoelectrochemical devices that exhibit efficient photocurrent generation.

基于SnO2为修饰层的Au-Pt / SnO2 / Au复合电极研究

用真空镀膜法在Au电极上沉积SnO₂薄膜，在HAuCl₄和H₂PtCl₄的混合溶液中利用直接还原法，将Au-Pt双金属纳米颗粒组装在SnO₂ / Au电极上，得到Au-Pt / SnO₂ / Au复合电极。采用SEM、TEM、XPS及CV曲线测定对Au-Pt / SnO₂ / Au复合电极进行了表征。结果表明:复合电极上双金属纳米颗粒分布均匀，粒子粒径约为25 nm左右。SnO₂作为修饰层以配位键与双金属纳米粒子结合。Au-Pt / SnO₂ / Au复合电极具有良好对甲醇氧化的电化学性能。
