Comparative study of solid-state reaction and sol-gel process for synthesis of Zr-doped Li<Subscript>0.5</Subscript>La<Subscript>0.5</Subscript>TiO<Subscript>3</Subscript> solid electrolytes

We investigated the synergistic influences of synthesis methods (solid-state reaction vs. sol-gel process) and Zr⁴⁺ doping on the structure and ionic conductivity of perovskite-structured Li_0.5La_0.5TiO₃ (LLTO) solid electrolytes. The lithium-ion conductivity of Li_0.5La_0.5Ti_1???x Zr _x O₃ ceramic specimens was evaluated as a function of x value and compared carefully between those two synthesis methods. Regarding the conductivity, sol-gel process is better for the synthesis of LLTO than solid-state reaction. As a result, the highest grain conductivity is obtained in the sol-gel-derived pure LLTO sample with x?=?0, reaching 1.10?×?10^?3 S?·?cm^?1. Partial substitution of Zr⁴⁺ enlarges the LLTO’s grain aggregate size and increases the total superficial area of aggregates. Consequently, Zr⁴⁺ substitution not only affects the grain (bulk) conductivity, but more importantly, also improves the grain boundary conductivity and the total conductivity. The highest total conductivity is 5.84?×?10^?5 S?·?cm^?1 with x?=?0.04 by sol-gel process.

Substitution effects on the bulk and surface properties of (Li,Ni)Mn<Subscript>2</Subscript>O<Subscript>4</Subscript>

Manganese oxides of spinel structure, LiMn₂O₄, Li_1-x Ni _x Mn₂O₄ (0.25 ≤ x≤ 0.75), and NiMn₂O₄, were studied by EDS, XRD, SEM, magnetic (M-H, M-T), and XPS measurements. The samples were synthesized by an ultrasound-assisted sol-gel method. EDS analysis showed good agreement with the formulations of the oxides. XRD and Rietveld refinement of X-ray data indicate that all samples crystallize in the Fd3m space group characteristic of the cubic spinel structure. The a-cell parameter ranges from a = 8.2276 Å (x = 0) to a = 8.3980 Å (x = 1). SEM results showed particle agglomerates ranging in size from 2.3 μm (x = 0) down to 0.8 μm (x = 1). Hysteresis magnetization vs. applied field curves in the 5–300K range was recorded. ZFC-FC measurements indicate the presence of two magnetic paramagnetic-ferrimagnetic transitions. The experimental Curie constant was found to vary from 5 to 7.1 cm³ K mol^?1 for the range of compositions studied (0 ≤ x ≤ 1). XPS studies of these oxides revealed the presence of Ni²⁺, Mn³⁺, and Mn⁴⁺. The experimental Ni/Mn atomic ratios obtained by XPS were in good agreement with the nominal values. A linear relationship of the average oxidation state of Mn with Ni content was observed. The oxide’s cation distributions as a function of Ni content from x = 0 ?Li⁺[Mn³⁺Mn⁴⁺]O₄ to x = 1 \( {\mathrm{Ni}}_{0.35}^{2+}{\mathrm{Mn}}_{0.65}^{3+}\left[{\mathrm{Ni}}_{0.65}^{2+}\right.\left.{\mathrm{Mn}}_{1.35}^{3+}\right]{\mathrm{O}}_4 \) were proposed.

Electrospinning preparation of one-dimensional Ce<Superscript>3+</Superscript>-doped Li<Subscript>4</Subscript>Ti<Subscript>5</Subscript>O<Subscript>12</Subscript> sub-microbelts for high-performance lithium-ion batteries

One-dimensional Ce³⁺-doped Li₄Ti₅O₁₂ (Li₄Ti_5?x Ce _x O₁₂, x?=?0, 0.01, 0.02, and 0.05) sub-microbelts with the width of approximately 500 nm and thickness of about 200 nm have been synthesized via the facile electrospinning method. The structure and morphology of the as-prepared samples are characterized by XRD, TEM, SEM, BET, HRTEM, XPS, and AFM. Importantly, one-dimensional Li₄Ti₅O₁₂ sub-microbelts can be well preserved with the introduction of Ce³⁺ ions, while CeO₂ impurity is obtained when x is greater than or equal to 0.02. The comparative experiments prove that Ce³⁺-doped Li₄Ti₅O₁₂ electrodes exhibit the brilliant electrochemical performance than undoped counterpart. Particularly, the reversible capacity of Li₄Ti_4.98Ce_0.02O₁₂ electrode reaches up to 139.9 mAh g^?1 and still maintains at 132.6 mAh g^?1 even after 100 cycles under the current rate of 4 C. The superior lithium storage properties of Li₄Ti_4.98Ce_0.02O₁₂ electrode could be attributed to their intrinsic structure advantage as well as enhanced overall conductivity.

Open image in new window

Graphical abstract ?



Magnetic properties of the Gd<Subscript>2</Subscript>V<Subscript>0.67</Subscript>Mo<Subscript>1.33</Subscript>O<Subscript>7</Subscript> and Y<Subscript>2</Subscript>VMoO<Subscript>7</Subscript> pyrochlore compounds

It is demonstrated that 50% substitution of vanadium for molybdenum in the pyrochlore lattice of the complex oxide Y₂(V _x Mo_{1 ? x} )₂O₇ results in a transition from the spin-glass ground state (at x = 0) to the ferromagnetic state in Y₂VMoO₇ (a = 10.1645(2) Å, T _C = 55 K). The Gd₂V_0.67Mo_1.33O₇ compound (a = 10.2862(3) Å) is a ferromagnet with T _C (84 K) exceeding that of undoped Gd₂MnO₂O₇.

Electrospun Dy-doped SrFe<Subscript>12</Subscript>O<Subscript>19</Subscript> nanofibers: microstructure and magnetic properties

SrDy _x Fe_12?x O₁₉ (x ≤ 0.08) nanofibers have been synthesized by the electrospinning method followed by calcinations process. The partial substitution of rare earth ions Dy³⁺ (10.5 μ _B of magnetic moments) mainly occupying 12k sublattice sites in the SrFe₁₂O₁₉ crystal structure is investigated and discussed in this work. An enhanced coercivity of 7155 Oe has been obtained when the doped content reached to 0.08 at a relative low calcination temperature of 800 °C. As a result, we believe the synthesized SrDy _x Fe_12?x O₁₉ nanofibers can potentially be useful in high-density recording media as well as permanent magnets.

The Nernst-Ettingshausen coefficient in the normal phase of doped HTSCs of the YBa<Subscript>2</Subscript>Cu<Subscript>3</Subscript>O<Subscript>y</Subscript> system

The temperature dependence of the Nernst-Ettingshausen coefficient Q(T) in the normal phase of doped HTSCs of the yttrium system was studied. The main features characterizing the behavior of this coefficient were revealed, and the character and mechanism of the effect that various nonisovalent substituents exert on the Q(T) dependence were analyzed. It is shown that the narrow-band model permits one not only to describe all the specific features observed in the Q(T) curves but also to perform a simultaneous quantitative analysis of the temperature dependences of four kinetic coefficients (the electrical resistivity and the Seebeck, Hall, and Nernst-Ettingshausen coefficients) with the use of a common set of model parameters characterizing the band structure and carrier system in the normal phase of an HTSC. This approach was employed to determine the carrier mobilities and the asymmetry of the dispersion curve in the systems studied (YBa₂Cu₃O_y, y = 6.37–6.91; YBa₂Cu_3?xCo_xO_y, x = 0–0.3; Y_1?xCa_xBa₂Cu₃O_y, x = 0–0.25; Y_1?xCa_xBa_2?xLa_xCu₃O_y, x = 0–0.5) and to analyze the effect of the substitutions involved on the variation of these parameters.

Spin-dimerization in rare-earth substituted La<Subscript>2</Subscript>RuO<Subscript>5</Subscript>

The Ru-Ru spin-singlet formation in La_2 ? x L n _x RuO₅ (Ln = Pr, Nd, Sm, Gd, Dy) was investigated by measurements of the specific heat and magnetic susceptibility. After subtraction of the lattice contribution from the specific heat (C _p ), similar excess entropy values were obtained for all compounds. These entropies can be explained by the formation of antiferromagnetic Ru-spin dimers at low temperatures and provide a lower estimate for the intradimer exchange strength. Pronounced changes in the transition temperatures and a broadening of the corresponding peak in C _p were observed. These changes depend on the rare-earth element and are due to local structural changes and heterogeneities caused by the substitution. The magnetic susceptibilities can be described by the sum of a rare-earth paramagnetic moment and the susceptibility of the unsubstituted La₂RuO₅. Density functional theory (DFT) calculations were performed for various compounds to investigate the origin of the magnetic transition and the relationship between structural changes and the spin-dimerization temperature. The combination of the present results with previous structural investigations supports the model of a spin-pairing of the Ru moments which occurs as a reason of the structural phase transition in La_2 ? x L n _x RuO₅.

Properties of Ca-containing LiCoPO<Subscript>4</Subscript>-graphitic carbon foam composites

LiCo_1???x Ca _x PO₄–graphitic carbon foam composites are prepared using a sol–gel method. The structural analysis reveals LiCoPO₄ as major crystalline phase and Co₂P₂O₇ (for x?=?0.0) and Co₂P, Li₃PO₄, and (Ca,Co)₃(PO₄)₂ (for x?≥?0.05) as secondary phases. The morphology consists of microcrystalline “islands” with acicular crystallites (5–50 μm size). Transmission electron microscopy (TEM) of the powders showed that the Ca is incorporated into the crystal structure evoking exaggerated grain growth. The voltammetric profiles show a decrease of the voltammetric surface between anodic and cathodic sweeps and a shift of the reduction potentials toward higher values (～4.6 V, x?=?0.1). The electrochemical measurements, at a discharge rate of C/10 (room temperature), show an increase of the discharge-specific capacity from 100 mAhg^?1 for x?=?0.0 to 104 mAhg^?1 for x?=?0.1. The ac impedance spectroscopy data revealed an improvement of the Li-ion conductivity at high content of Ca ions (x?=?0.1).

Conductivity and spectroscopic studies of Li<Subscript>2</Subscript>O-V<Subscript>2</Subscript>O<Subscript>5</Subscript>-B<Subscript>2</Subscript>O<Subscript>3</Subscript> glasses

Lithium vanadium-borate glasses with the composition of 0.3Li₂O–(0.7-x)B₂O₃–xV₂O₅ (x?=?0.3, 0.325, 0.35, 0.375, 0.4, 0.425, 0.45, and 0.475) were prepared by melt-quenching method. According to differential scanning calorimetry data, vanadium oxide acts as both glass former and glass modifier, since the thermal stability of glasses decreases with an increase in V₂O₅ concentration. Fourier transform infrared spectroscopy data show that the vibrations of [VO₄] structural units occur at V₂O₅ concentration of 45 mol%. It is established that the concentration of V⁴⁺ ions increases exponentially with the growth of vanadium oxide concentration. Direct and alternative current measurements are carried out to estimate the contribution both electronic and ionic conductivities to the value of total conductivity. It is shown that the electronic conductivity is predominant in the total one. The glass having the composition of 0.3Li₂O-0.275B₂O₃-0.475V₂O₅ shows the highest electrical conductivity that has the value of 7.4?×?10^?5 S cm^?1 at room temperature.

Investigation of the structural and electrochemical performance of Li<Subscript>1.2</Subscript>Ni<Subscript>0.2</Subscript>Mn<Subscript>0.6</Subscript>O<Subscript>2</Subscript> with Cr doping

Cr-doped layered oxides Li[Li_0.2Ni_0.2???x Mn_0.6???x Cr_2x ]O₂ (x?=?0, 0.02, 0.04, 0.06) were synthesized by co-precipitation and high-temperature solid-state reaction. The materials were characterized by X-ray diffraction (XRD), scanning electron microscopy (SEM), high-resolution transmission electron microscopy (TRTEM), X-ray photoelectron spectroscopy (XPS), and electrochemical impedance spectroscopy (EIS). XRD patterns and HRTEM results indicate that the pristine and Cr-doped Li_1.2Ni_0.2Mn_0.6O₂ show the layered phase. The Li_1.2Ni_0.16Mn_0.56Cr_0.08O₂ shows the best electrochemical properties. The first discharge specific capacity of Li_1.2Ni_0.16Mn_0.56Cr_0.08O₂ is 249.6 mA h g^?1 at 0.1 C, while that of Li_1.2Ni_0.2Mn_0.6O₂ is 230.4 mA h g^?1. The capacity retaining ratio of Li_1.2Ni_0.16Mn_0.56Cr_0.08O₂ is 97.9% compared with 93.9% for Li_1.2Ni_0.2Mn_0.6O₂ after 80 cycles at 0.2 C. The discharge capacity of Li_1.2Ni_0.16Mn_0.56Cr_0.08O₂ is 126.2 mA h g^?1 at 5.0 C, while that of the pristine Li_1.2Ni_0.2Mn_0.6O₂ is about 94.5 mA h g^?1. XPS results show that the content of Mn³⁺ in the Li_1.2Ni_0.2Mn_0.6O₂ can be restrained after Cr doping during the cycling, which results in restraining formation of spinel-like structure and better midpoint voltages. The lithium-ion diffusion coefficient and electronic conductivity of Li_1.2Ni_0.2Mn_0.6O₂ are enhanced after Cr doping, which is responsible for the improved rate performance of Li_1.2Ni_0.16Mn_0.56Cr_0.08O₂.

Internal friction of Li<Subscript>2</Subscript>B<Subscript>4</Subscript>O<Subscript>7</Subscript> single crystals

This paper reports on the results of measurements of the internal friction Q^?1 and the shear modulus G of Li₂B₄O₇ single crystals along the crystallographic directions [100] and [001] in the temperature range 300–550 K for strain amplitudes of (2–10)×10^?5 at infralow frequencies. The anomalies observed in Q^?1 and G in the temperature range 390–410 K are due to thermal activation of the mobility of lithium cations and their migration from one energetically equivalent position to another. A jump in the internal friction background is revealed in the vicinity of the Q^?1 and G anomalies for the Li₂B₄O₇ crystal. The magnitude of this jump depends on the crystallographic direction.

High-temperature complex impedance and modulus spectroscopic studies of doped Na<Subscript>0.5</Subscript>Bi<Subscript>0.5</Subscript>TiO<Subscript>3</Subscript>-BaTiO<Subscript>3</Subscript> ferroelectric ceramics

Lead-free Na_0.5Bi_0.5TiO₃ (NBT) and (1 ? x)Na_0.5Bi_0.5TiO₃ + xBaTiO₃ with x = 0.1 and 0.2 (where x = 0.1 and 0.2 are named as NBT1 and NBT2, respectively), (1 ? y)Na_0.5Bi_0.5TiO₃ + yBa_0.925Nd_0.05TiO₃ with y = 0.1 and 0.2 (where y = 0.1 and 0.2 are named as NBT3 and NBT4, respectively)-based relaxor ferroelectric ceramics were prepared using the sol-gel method. The crystal structure was investigated by X-ray diffraction (XRD) at room temperature (RT). The XRD patterns confirmed the presence of the rhombohedral phase in all the samples. The electrical properties of the present NBT-based samples were investigated by complex impedance and the modulus spectroscopy technique in the temperature range of RT–600 °C. The AC conductivity was found to increase with the substitution of Ba²⁺ ions to the NBT sample whereas it significantly decreased with the addition of Nd³⁺ ions. The more anion vacancies in Ba-added samples and the lower anion vacancies in Nd-added samples were found to be responsible for higher and lower conductivities, respectively.

Structural and magnetic phase transformations in the BiFeO<Subscript>3</Subscript>-CaFe<Subscript>0.5</Subscript>Nb<Subscript>0.5</Subscript>O<Subscript>3</Subscript> system

The crystal structure and magnetic properties of the Bi_{1 ? x} Ca _x Fe_{1 ? x/2}Nb _x/2O₃ system were studied. It is shown that, at x ≤ 0.15, the unit-cell symmetry of solid solutions is rhombohedral (space group R3c). Solid solutions with x ≥ 0.3 have an orthorhombic unit cell (space group Pbnm). The rhombohedral compositions are antiferromagnetic, while the orthorhombic compositions exhibit a small spontaneous magnetization due to Dzyaloshinski?-Moriya interaction. In CaFe_0.5Nb_0.5O₃, the Fe³⁺ and Nb⁵⁺ ions are partially ordered and the unit cell is monoclinic (space group P2₁/n). In the concentration range 0.15 < x < 0.30, a two-phase state (R3c + Pbnm) is revealed.

Studies on structural and electrical properties of Mg<Subscript>0. 5+y</Subscript> (Zr<Subscript>2-y</Subscript>Fe<Subscript>y</Subscript>) <Subscript>2</Subscript> (PO<Subscript>4</Subscript>) <Subscript>3</Subscript> ceramic electrolytes

The sample of Mg_{0. 5+y} (Zr_1-y Fe_y) ₂ (PO₄) ₃ (0.0 ≤y ≤0.5) was synthesized using the sol-gel method. The structures of the samples were investigated using X-ray diffraction and Fourier transform infrared spectroscopy measurement. XRD studies showed that samples had a monoclinic structure which was iso-structured with the parent compound, Mg_0.5Zr (PO₄) ₃. The complex impedance spectroscopy was carried out in the frequency range 1–6 MHz and temperature range 303 to 773 K to study the electrical properties of the electrolytes. The substitutions of Fe³⁺ with Zr⁴⁺ in the Mg_0.5Zr (PO₄) ₃ structure was introduced as an extrainterstitial Mg²⁺ ion in the modified structured. The compound of Mg_0.5+y (Zr_1-y Fe_y)₂(PO₄)₃ with y?=?0.4 gives a maximum conductivity value of 1.25?×?10^?5 S cm^?1 at room temperature and 7.18?×?10^?5 S cm^?1 at 773 K. Charge carrier concentration, mobile ion concentration, and ion hopping rate are calculated by fitting the conductance spectra to power law variation, σ _ac (ω)?=?σ _o ? +?Aω ^α . The charge carrier concentration and mobile ion concentration increases with increase of Fe³⁺ inclusion. This implies the increase in conductivity of the compounds was due to extra interstitial Mg²⁺ ions.

Structure,ionic conduction,and phase transformations in lithium titanate Li<Subscript>4</Subscript>Ti<Subscript>5</Subscript>O<Subscript>12</Subscript>

The spinel structure of lithium titanate Li₄Ti₅O₁₂ is refined by the Rietveld full-profile analysis with the use of x-ray and neutron powder diffraction data. The distribution and coordinates of atoms are determined. The Li₄Ti₅O₁₂ compound is studied at high temperatures by differential scanning calorimetry and Raman spectroscopy. The electrical conductivity is measured in the high-temperature range. It is shown that the Li₄Ti₅O₁₂ compound with a spinel structure undergoes two successive order-disorder phase transitions due to different distributions of lithium atoms and cation vacancies (□, V) in a defect structure of the NaCl type: (Li)_8a[Li_0.33Ti_1.67]_16dO₄ → [Li□]_16c[Li_1.33Ti_1.67]_16dO₄ → [Li_1.33□_0.67]_16c[Ti_1.67□_0.33]_16dO₄. The low-temperature diffusion of lithium predominantly occurs either through the mechanism ... → Li(8a) → V(16c) → V(8a) → ... in the spinel phase or through the mechanism ... → Li(16c) → V(8a) → V(16c) → ... in an intermediate phase. In the high-temperature phase, the lithium cations also migrate over 48f vacancies: ... Li(16c) → V(8a, 48f) → V(16c) → ....

EPR study of copper ions in Li<Subscript>2</Subscript>Ge<Subscript>7</Subscript>O<Subscript>15</Subscript> crystals

The EPR spectra of Cu²⁺ ions (² D _5/2) located at two structurally nonequivalent positions Cu1 and Cu2 in crystals of lithium heptagermanate Li₂Ge₇O₁₅ are recorded. The angular dependences of the EPR spectrum are measured in the paraelectric phase of the Li₂Ge₇O₁₅ compound (T = 300 K). The components of the g factor and the hyperfine interaction tensor A are determined, and the orientation of the magnetic axes with respect to the crystallographic basis is established. The EPR spectra are recorded in the temperature range in the vicinity of the temperature T _C = 283 K of the transition from the paraelectric phase to the ferroelectric phase. The position symmetry of the Cu1 and Cu2 centers is determined at temperatures above and below the phase transition temperature T _C . The localization of paramagnetic centers in the structure is discussed, An analysis of the results obtained demonstrates that the Cu1 and Cu2 centers in the Li₂Ge₇O₁₅ crystal lattice replace lithium ions located at two structurally nonequivalent positions with the symmetries described at temperatures above T _C by the triclinic C _i and monoclinic C ₂ point groups, respectively.

Solid state synthesis of nonstoichiometric Bi<Subscript>2</Subscript>WO<Subscript>6</Subscript>/Bi<Subscript>2</Subscript>O<Subscript>3</Subscript> composites as visible-light photocatalyst

Nonstoichiometric Bi₂WO₆ photocatalyst with the composition of Bi_2?+?x WO_6?+?1.5x (?0.25 ≤ x ≤ 1) wa synthesized by a facile solid state reaction method. The products were characterized by X-ray diffraction (XRD), scanning electron microscopy (SEM), and UV-vis absorption spectrum. The Bi_2.5WO_6.75 photocatalyst showed excellent visible-light-driven photocatalytic performance; nearly 100 % of RhB (10 ppm, pH?=?3?~?4) was decomposed within 25 min, which demonstrated that nonstoichiometric semiconductors could be an efficient visible-light-driven photocatalyst.

Pressure-induced structural transformations,orbital order and antiferromagnetism in La<Subscript>0.75</Subscript>Ca<Subscript>0.25</Subscript>MnO<Subscript>3</Subscript>

High pressure evolution of structural, vibrational and magnetic properties of La_0.75Ca_0.25MnO₃ was studied by means of X-ray diffraction and Raman spectroscopy up to 39 GPa, and neutron diffraction up to 7.5 GPa. The stability of different magnetic ground states, orbital configurations and structural modifications were investigated by LDA + U electronic structure calculations. A change of octahedral tilts corresponding to the transformation of orthorhombic crystal structure from the Pnma symmetry to the Immaone occurs above P ~ 6 GPa. At the same time, the evolution of the orthorhombic lattice distortion evidences an appearance of the e _g d _{x² ? z²} orbital polarization at high pressures. The magnetic order in La_0.75Ca_0.25MnO₃ undergoes a continuous transition from the ferromagnetic 3D metallic (FM) ground state to the A-type antiferromagnetic (AFM) state of assumedly 2D pseudo-metallic character under pressure, that starts at about 1 GPa and extends possibly to 20–30 GPa.

Nonstoichiometric high-pressure phase of Tm<Subscript><Emphasis Type="Italic">x</Emphasis></Subscript>Cu<Subscript>3</Subscript>V<Subscript>4</Subscript>O<Subscript>12</Subscript>

Tm _x Cu₃V₄O₁₂, a perovskite-like oxide (space group, Im-3; Z = 2; a = 7.279–7.293 Å) containing vacancies in its cationic sublattice, was obtained barothermally (P = 7.0–9.0 GPa, t = 1000–1100°C) for the first time. The temperature dependences on the electrical resistivity (10–300 K) and the magnetic susceptibility (0–300 K) were investigated. It was shown that the oxide Tm _x Cu₃V₄O₁₂ is characterized by metal-type conductivity and paramagnetic properties.

Effect of heterovalent substitution of rare-earth elements on the magnetic and transport properties of YBa<Subscript>2</Subscript>Cu<Subscript>3</Subscript>O<Subscript>7</Subscript>

The Y_{(1 ? x} Ce _x Ba₂Cu₃O₇ system with low cerium concentrations has been synthesized. The cerium solubility limit measured using x-ray powder diffraction analysis is about 2.4 at. %. The temperature dependences of the magnetization M(T) are measured for samples cooled in a magnetic field (FC) and in a zero field (ZFC). The difference between the magnetizations M _ZFC-M _FC at 77.4 K, which is proportional to the pinning potential, passes through a maximum at x = 0.0156. This concentration corresponds to the average distance (equal to eight lattice constants) between the impurity ions in the plane of the rare-earth elements, which is comparable to the diameter of Abrikosov vortices in YBa₂Cu₃O₇.
